Gain Controller , control the input level of MIC/LINE or INST channel, adjust to balance the volume.
Phantom Power Button/LED, when te button is turned on, the LED light is on, provide DC+48V phantom power to XLR plug on MIC/LINE input.
Power Cosumption 2.5w 1mic/line+1 inst , 3w 2 mic/line
Power OutputCurrent 1A
Power Output Voltage DC5V
Phantom Power Voltage +48V DC
Output Channels MONITOR OUT: L/R(RCA) ,
PHONES: 6.35mm Jack
Input Channels MIC/LINE: 1 Combo Jack (XLR+6.35mm) , 2 Combo Jack (XLR+6.35mm)
Interface 2.0 USB Type-B
Audio Sampling Rate 24 Bit 48kHz for play and record
Free Drivers
